Ventiladores centrífugos de baja presión CENTRIFUGAL LOW PRESSURE FANS 183 CV092024 MANUFACTURING FEATURES • Galvanised steel sheet housing. • Polyamide impeller reinforced with fibreglass in models 7/7, 9/9, 10/10 and 12/12. The impeller of the rest of models are made of galvanised steel sheet. • Double inlet forward curved impeller in all models. • Supplied with mounting feet (included in price). • Motor fixing with an exclusive system designed by Casals through flexible arms and silent blocks to avoid vibration. Flexible arms in compliance with the ROHS 2002/95/EC Directive (Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipments). • Closed motors specially designed by Casals: extruded aluminiummotor housing, wiring box fit in the motor with IP-65 protection. Motor with IP-55 protection and Class F insulation. Manufactured with standard voltages: 230V 50 Hz in single phase motors and 230/400V 50 Hz in three phase motors. • Single phase motors with controllable voltage speed. Three phase motors controllable using a frecuency speed controller. APPLICATIONS Designed for assembly in equipment: • Ventilation boxes and air handling units. • Centrifugal heaters. • Industrial and professional kitchen hoods. Use in supply or extraction with prior fat filtering. • Maximum working temperature: 50ºC for single phase motors and 60ºC for three phase motors. UNDER REQUEST • Impeller made of galvanized steel sheet. • MBI assembled. CARACTERÍSTICAS CONSTRUCTIVAS • Envolvente en chapa galvanizada. • Turbina de poliamida reforzada con fibra de vidrio para tamaños 7/7, 9/9, 10/10 y 12/12. Resto de modelos en chapa galvanizada. • Turbina multipala de álabes curvados hacia delante de doble oído. • El ventilador se suministra con los pies soporte incluidos en el precio. • Sistema exclusivo Casals de fijación del motor al ventilador y a la turbina mediante brazos flectores que unidos a silent blocks evitan cualquier tipo de vibración. Brazos en cumplimiento con la directiva ROHS 2002/95/EC (Restricción de sustancias peligrosas en equipos eléctricos y electrónicos). • Motores cerrados de diseño exclusivo Casals con carcasa de aluminio extruido, que hacen que todo el conjunto de conexiones quede protegido dentro de la caja de bornes integrada en el motor con protección IP-65. Motor con protección IP-54 y aislamiento clase F. Voltajes estándar 230V 50Hz para motores monofásicos y 230/400V 50Hz para motores trifásicos. • Motores monofásicos regulables por tensión. Modelos trifásicos regulables mediante variador de frecuencia. APLICACIONES Diseñados para ser integrados en equipos: • Cajas de ventilación y unidades de tratamiento de aire. • Aerotermos centrífugos. • Campanas de cocina industriales y profesionales. Uso en aportación o en extracción con previo filtrado de grasas. • Temperatura máxima de trabajo en continuo: 50ºC para motores monofásicos y 60ºC para motores trifásicos. BAJO DEMANDA • Turbina chapa galvanizada. • MBI montado. BD Double inlet Doble aspiración 60 +info Hz ErP ACCESSORIES / accesorios INT SFC REG MBI Interruptor de corte Variador de velocidad frecuencial Regulador de velocidad manual monofásico Marco brida impulsión Safety switch Frecuency speed controller Single phase manual speed controller Outlet flange RA RM RI Rejilla aspiración Reja motor Reja impulsión Inlet protection guard Motor guard Outlet guard
Ventiladores centrífugos de baja presión CENTRIFUGAL LOW PRESSURE FANS 184 CV092024 Code Model R.P.M Rated I (A) 230V Rated Power kW Air flow m3/h Sound dB (A) Weight Kg Connection diagram 251160260 BD 7/7 M6 0,04kW 885 0,6 0,04 1.080 44 9 1 251260261 BD 9/7 M6 0,13kW 940 1,3 0,13 2.050 50 14 1 251280261 BD 9/9 M6 0,13kW 940 1,3 0,13 2.240 53 15 1 251330261 BD 10/8 M6 0,21kW 945 2,1 0,21 2.625 56 17 1 251370261 BD 10/10 M6 0,21kW 945 2,1 0,21 2.860 56 15,5 1 251600261 BD 12/9 M6 0,76kW 950 6,7 0,76 5.860 59 21 1 251520261 BD 12/12 M6 0,76kW 950 6,7 0,76 6.275 59 27 1 Code Model Rated R.P.M Rated I (A) Rated Power kW Air flow m3/h Sound dB (A) Weight Kg Connection diagram 230V 400V 251600161 BD 12/9 T6 1,1kW 945 6,54 3,78 1,1 6.200 59 26 2 251520160 BD 12/12 T6 1,1kW 945 6,54 3,78 1,1 6.450 59 27 2 252370106 BD 15/15 T6 2,2kW 900 10,92 6,31 2,2 10.600 64 57 2 6 POLE / 6 polos THREE PHASE RANGE / serie trifásica 6 POLE / 6 polos SINGLE PHASE RANGE / serie monofásica Code Model R.P.M Rated I (A) 230V Rated Power kW Air flow m3/h Sound dB (A) Weight Kg Connection diagram 251100261 BD 7/7 M4 0,13kW 1370 1,55 0,13 1.940 59 9 1 251270260 BD 9/7 M4 0,35kW 1375 2,7 0,35 2.540 60 15 1 251220260 BD 9/9 M4 0,35kW 1375 2,7 0,35 2.810 61 12 1 251340260 BD 10/8 M4 0,59kW 1340 4,5 0,59 3.440 63 22 1 251320260 BD 10/10 M4 0,59kW 1340 4,5 0,59 3.780 64 22 1 4 POLE / 4 polos ErP ErP ErP
Ventiladores centrífugos de baja presión CENTRIFUGAL LOW PRESSURE FANS 185 CV092024 DIMENSIONS / dimensiones (mm) Model A B max C D E F G H I J N X BD 7/7 M4 0,12kW 230 302 259 245 48,5 9,5 337 150 316 153 208 158 BD 7/7 M4 0,13kW 230 302 259 245 48,5 9,5 337 150 316 153 208 158 BD 7/7 M6 0,04kW 230 277 259 245 48,5 9,5 337 150 316 153 208 158 BD 9/7 M4 0,35kW 233 287 262 245 70 19 407 191 376 184 260 202 BD 9/7 M6 0,12kW 233 284 262 245 70 19 407 191 376 184 260 202 BD 9/7 M6 0,13kW 233 284 262 245 70 19 407 191 376 184 260 202 BD 9/9 M4 0,35kW 301 354,5 330 245 70 19 407 191 376 184 260 202 BD 9/9 M6 0,12kW 301 352 330 245 70 19 407 191 376 184 260 202 BD 9/9 M6 0,13kW 301 352 330 245 70 19 407 191 376 184 260 202 BD 10/8 M4 0,59kW 265 339 294 350 70,5 20 464 214 420 198 291 220 BD 10/8 M6 0,19kW 265 333 294 350 70,5 20 464 214 420 198 291 220 BD 10/8 M6 0,21kW 265 333 294 350 70,5 20 464 214 420 198 291 220 BD 10/10 M4 0,59kW 329 384 359 350 70,5 20 464 214 420 198 291 220 BD 10/10 M6 0,19kW 329 368 359 350 70,5 20 464 214 420 198 291 220 BD 10/10 M6 0,21kW 329 384 359 350 70,5 20 464 214 420 198 291 220 BD 12/9 M6 0,76kW 310 380 339 350 77 17 536 244 490 230 343,5 260 BD 12/9 M6 0,79kW 310 389 339 350 77 17 536 244 490 230 343,5 260 BD 12/9 T6 1,1kW 310 380 339 350 77 17 536 244 490 230 343,5 260 BD 12/12 M6 0,76kW 396 437 425 350 77 17 536 244 490 230 343,5 260 BD 12/12 T6 1,1kW 396 437 425 350 77 17 536 244 490 230 343,5 260 J B H I N F G E D C A X int. CONNECTION DIAGRAMS / esquema de conexiones 1 SINGLE PHASE MOTORS / motores monofásicos 2 THREE PHASE MOTORS 1 SPEED / motores trifásicos 1 velocidad L N C rojo blanco negro red white black W2 U2 V2 L1 L2 L3 L1 L2 L3 W2 U2 V2 U1 V1 W1 U1 V1 W1
Ventiladores centrífugos de baja presión CENTRIFUGAL LOW PRESSURE FANS 186 CV092024 CHARACTERISTIC CURVES / curvas características 1 2 34 5 6 1 2 3 4 5 6 0 500 1000 1500 2000 2500 3000 3500 4000 4500 Q (m3/h) 0 500 1000 1500 2000 2500 Q (CFM) 0 5 10 15 20 25 30 35 40 45 50 Ps (mmH2O) 0 49 98 147 196 245 294 343 392 441 490 Ps (Pa) 0,00 0,10 0,20 0,30 0,40 0,50 0,60 0,70 0,80 0,90 1,00 1,10 Pabs (kW) BD 7/7 M4 0,12kW* 1 BD 7/7 M4 0,13kW 2 BD 9/7 M4 0,35kW 3 BD 9/9 M4 0,35kW 4 BD 10/8 M4 0,59kW 5 BD 10/10 M4 0,59kW 6 4 POLE / 4 polos 1 2 3 4 5 6 7 8 9 101 1 2 3 4 5 6 7 9 8 10 11 0 1000 2000 3000 4000 5000 6000 Q (m3/h) 0 500 1000 1500 2000 2500 3000 3500 Q (CFM) 0 5 10 15 20 25 30 35 Ps (mmH2O) 0 49 98 147 196 245 294 343 Ps (Pa) 0,00 0,20 0,40 0,60 0,80 1,00 1,20 1,40 1,60 Pabs (kW) BD 7/7 M6 0,04kW 1 BD 9/7 M6 0,12kW* 2 BD 9/7 M6 0,13kW 3 BD 9/9 M6 0,12kW* 4 BD 9/9 M6 0,13kW 5 BD 10/8 M6 0,19kW* 6 BD 10/8 M6 0,21kW 7 BD 10/10 M6 0,19kW* 8 BD 10/10 M6 0,21kW 9 BD 12/9 M6 0,76kW 10 BD 12/12 M6 0,76kW 11 6 POLE / 6 polos 1 2 1 2 0 1000 2000 3000 4000 5000 6000 7000 8000 Q (m3/h) 0 500 1000 1500 2000 2500 3000 3500 4000 4500 Q (CFM) 0 5 10 15 20 25 30 35 Ps (mmH2O) 0 49 98 147 196 245 294 343 Ps (Pa) 0,00 0,20 0,40 0,60 0,80 1,00 1,20 1,40 1,60 Pabs (kW) BD 12/9 T6 1,1kW 1 BD 12/12 T6 1,1kW 2 6 POLE / 6 polos
