BM-D CBM-D CBM-D/AL CBM-D Silent
BM-D VENTILATEUR CENTRIFUGE, BASSE PRESSION AVEC MOTEUR DIRECT Caractéristiques • Débits: de 1.700 à 10.200m3/ h. • Enveloppe et turbine en tôle d'acier galvanisé, turbine à action, double aspiration, avec ailettes incurvées vers l'avant. • Turbine dynamiquement équilibrée selon ISO 1940, pour réduire le bruit et éviter les vibrations. • Moteur de boîte de connexion intégré. • Moteur électrique de type fermé, isolation type F, IP55, avec boîtier en aluminium. • Condensateur permanent. 4 ou 6 pôles réglables par tension dans les moteurs monophasés 230V-50 Hz et réglables en option avec convertisseur de fréquence dans les moteurs triphasés 230 / 400V 50 Hz. • Fixation du moteur au moyen de bras de cintrage avec silentblocks conformément à la directive ROHS 2002/95 / CE. • Sur demande, des ventilateurs à trois vitesses peuvent être fournis en certain models (priere de nous consulter). • Les pieds de support inclus permettent quatre positions de la bouche de décharge. • La température de l'air ne doit pas dépasser 45°C CBM-D BOÎTE DE VENTILATION • Caisson ventilation fabriqué en tôle d’acier galvaniseé avec isolation thermique et acoustique. CBM-D/AL BOÎTE DE VENTILATION • Caisson ventilation fabriqué en profil d’aluminium et panneaux interchangables. BM-D LOW PRESSURE CENTRIFUGAL FAN WITH DIRECT MOTOR Characteristics • Flow rates: from 1.700 to 10.200m3/ h. • Galvanized steel sheet casing and turbine, the action type impeller, double suction, with forward curved flaps. • Dynamically balanced turbine in compliance with ISO 1940 standards, to reduce noise and avoid vibrations. • Integrated connection box motor. • Closed type electric motor, type F insulation, IP55, with aluminium casing. • Permanent capacitor. 4 or 6 poles adjustable by voltage in single-phase 230V-50 Hz motors and adjustable in opcion with frequency converter in three-phase 230 / 400V 50 Hz motors. • Motor secured by means of bending clamps with silent blocks in compliance with the ROHS 2002/95 / EC.standard • On demand, three-speed fans can be supplied in some specific models. • The included support feet allow four positions of the discharge mouth. • The air temperature must not exceed 45°C. CBM-D VENTILATION BOX • Ventilation unit made on galvanised steel sheet with thermal and acustic isolation. CBM-D/AL VENTILATION BOX • Ventilation unit made on aluminiun structure and galvanised steel sheets, panels interchangeable. ErP BM-D • CBM-D • CBM-D/AL • CBM-D Silent BM-D VENTILADOR CENTRÍFUGO DE BAJA PRESIÓN CON MOTOR DIRECTO Características • Caudales: desde 1.700 hasta 10.200m3/h. • Envolvente y turbina en chapa de acero galvanizado, el rodete de tipo acción, doble aspiración, con aletas curvadas hacia delante. • Turbina equilibrada dinámicamente según norma ISO 1940, para reducir el ruido y evitar vibraciones. • Motor caja conexionado integrada. • Motor eléctrico acoplado de tipo cerrado, aislamiento tipo F(IP55) con carcasa de aluminio. • Condensador permanente. De 4 ó 6 polos regulables por tensión en motores monofásicos 230V-50 Hz y regulables opcionalmente con convertidor de frecuencia en motores trifásicos 230/400V 50 Hz. • Fijación del motor mediante brazos flectores con silentblocks en cumplimiento de la directiva ROHS 2002/95/EC. • Bajo demanda se pueden suministrar ventiladores de tres velocidades en determinados modelos (consultar). • Los pies soporte incluidos permiten cuatro posiciones de la boca de descarga. • La temperatura del aire no debe sobrepasar los 45°C. CBM-D CAJA DE VENTILACIÓN • Unidad de ventilación fabricada en chapa galvanizada con aislamiento. CBM-D/AL CAJA DE VENTILACIÓN • Unidad de ventilación fabricada con perfil de aluminio y paneles intercambiables. Luymar se reserva el derecho a modificar los datos sin previo aviso.
Filtro opcional * Potencia sonora a 1m. BM-D • CBM-D • CBM-D/AL • CBM-D Silent Luymar se reserva el derecho a modificar los datos sin previo aviso. En cumplimiento del reglamento europeo 1253/2014 se debe incorporar variador / convertidor de frecuencia. ErP MODELO Serie monofásica Single phase 7/7 M4 1/5 cv 7/7 M4 1/2 cv 9/7 M4 1/2 cv 9/7 M4 3/4 cv 9/9 M6 1/5 cv 9/9 M6 1/3 cv 9/9 M4 1/2 cv 9/9 M4 3/4 cv 10/8 M4 3/4 cv 10/10 M6 1/3 cv 10/10 M4 1/2 cv 10/10 M4 3/4 cv 12/12 M6 3/4 cv 12/12 M6 1 cv max R.P.M. 1230 1320 1320 1310 850 830 1320 1310 1310 830 1320 1310 850 850 Código BM-D 0301070701 0301070703 0301090703 0301090704 0301090901 0301090902 0301090903 0301090904 0301100804 0301101002 03011010032 0301101004 0301121204 0301121205 Potencia (kW) 0,15 0,37 0,37 0,55 0,15 0,25 0,37 0,55 0,55 0,25 0,37 0,55 0,55 0,75 Caudal máx (m3/h) 1750 2600 2800 3250 2500 3100 3000 3400 3200 3250 2700 3400 5600 5900 dB (A)* 66 67 71 72 64 65 75 76 74 65 71 73 68 71 Intensidad max. (A) 230V 1,4 3,3 3,3 4 1,5 2,2 3,3 4,5 4 2,2 3,3 4,5 5 6 Código CBM-D 0302070701 0302070703 0302090703 0302090704 0302090901 0302090902 0302090903 0302090904 0302100804 0302101002 03021010032 0302101004 0302121204 0302121205 CBM-D Silent dB (A)* 53 54 57 58 51,4 53 61,3 62 59,6 53 58 60,5 56 58 MODELO Serie Trifásica Three phasea 12/12 T6 1,5 cv 15/15 T6 3 cv max R.P.M. 850 890 Potencia (kW) 1,1 2,2 Caudal máx (m3/h) 7.200 10.200 dB (A)* 78 67 Intensidad max. (A) 230V 6,6 10,9 400V 3,8 6,3 03011212062 0301151510 03021212062 0302151510 CBM-D Silent dB (A)* 64,6 55 Código BM-D Código CBM-D
BM-D • VENTILADOR CENTRÍFUGO DE BAJA PRESIÓN MOTOR DIRECTO BM-D • CBM-D • CBM-D/AL • CBM-D Silent Luymar se reserva el derecho a modificar los datos sin previo aviso. A B C D max E F G H I J max K L CBM-D • VENTILADOR CENTRÍFUGO DE BAJA PRESIÓN CON MOTOR DIRECTO CON CAJA CBM-D/AL • CAJA DE VENTILACIÓN CON MOTOR DIRECTO EN PERFILERÍA DE ALUMINIO ErP 7/7 9/7 9/9 10/8 10/10 12/9 12/12 15/15 A 307 375 375 427 427 498 498 578 B 320 394 394 447 447 526 526 617 C 258 273 324 296 348 330 406 500 D 264 313 352 332 448 439 476 525 E 209 265 265 290 290 342 342 404 F 232 250 298 274 326 309 386 473 G 146 180 180 207 207 236 236 271 H 180 218 218 245 245 292 292 343 I 27 33 33 38 38 38 38 38 J 32 63 54 58 122 130 90 52 K 228 280 280 317 317 400 400 460 MODELO L 55 75 75 80 80 82 82 91 BOCA IMPULSIÓN BOCA ASPIRACIÓN MODELO CBM-D - 7/7 CBM-D - 9/9 CBM-D - 10/10 CBM-D - 12/12 CBM-D - 15/15 A 505 555 605 705 800 B 375 445 505 570 755 C 380 430 480 570 700 K 30 30 30 30 30 D 220 280 305 353 416 E 240 315 335 400 435 F 125 137 170 195 260 G 410 465 515 615 705 H 270 355 410 480 660 G H D C A B D F F K K = = E C D G H A B E D F F BOCA IMPULSIÓN BOCA ASPIRACIÓN MODELO CBM-D - 7/7 CBM-D - 9/9 CBM-D - 10/10 CBM-D - 12/12 CBM-D - 15/15 A 505 555 605 705 800 B 375 445 505 570 755 C 380 430 480 570 700 K 30 30 30 30 30 D 220 280 305 353 416 E 240 315 335 400 435 F 125 137 170 195 260 G 410 465 515 615 705 H 270 355 410 480 660
BM-D • CBM-D • CBM-D/AL • CBM-D Silent Luymar se reserva el derecho a modificar los datos sin previo aviso. 7/7 M4 1/5 cv 7/7 M4 1/2 cv 9/7 M4 1/2 cv 9/7 M4 3/4 cv Pr.Estática/Static Pr.(Pa) 300 250 200 150 100 50 0 0 500 250 700 1250 1000 1500 2000 1750 A 3,0 2,0 1,0 0,0 Caudal/Flow Rate (m3/h) Pr.Estática/Static Pr.(Pa) 300 250 200 150 100 50 0 0 500 1000 1500 2000 A 4,0 3,0 2,0 1,0 Caudal/Flow Rate (m3/h) 2500 2000 Pr.Estática/Static Pr.(Pa) 500 450 400 350 200 50 0 0 500 1000 1500 2000 A 4,0 3,0 2,0 1,0 Caudal/Flow Rate (m3/h) 2500 2000 300 250 100 150 Pr.Estática/Static Pr.(Pa) 500 450 400 350 200 50 0 0 500 1000 1500 2000 A 4,0 3,0 2,0 1,0 Caudal/Flow Rate (m3/h) 4000 300 250 100 150 2500 3000 3500 ErP
BM-D • CBM-D • CBM-D/AL • CBM-D Silent 9/9 M6 1/5 cv 9/9 M6 1/3 cv 9/9 M4 1/2cv 9/9 M4 3/4 cv Luymar se reserva el derecho a modificar los datos sin previo aviso. Pr.Estática/Static Pr.(Pa) 300 200 150 100 50 0 0 500 1500 1000 2000 2500 A 3,0 2,0 1,0 Caudal/Flow Rate (m3/h) Pr.Estática/Static Pr.(Pa) 250 200 150 100 50 0 0 500 1000 1500 2000 A 4,0 3,0 2,0 1,0 Caudal/Flow Rate (m3/h) 2500 3500 3000 Pr.Estática/Static Pr.(Pa) 450 400 350 200 50 0 1000 1500 2000 A 4,0 3,0 2,0 1,0 Caudal/Flow Rate (m3/h) 2500 3000 300 250 100 150 500 3500 Pr.Estática/Static Pr.(Pa) 500 450 400 350 200 50 0 0 500 1000 1500 2000 A 4,0 3,0 2,0 1,0 Caudal/Flow Rate (m3/h) 4000 300 250 100 150 2500 3000 3500 ErP
BM-D • CBM-D • CBM-D/AL • CBM-D Silent 10/8 M4 3/4 cv 10/10 M6 1/3 cv 10/10 M4 1/2 cv 10/10 M4 3/4 cv Luymar se reserva el derecho a modificar los datos sin previo aviso. Pr.Estática/Static Pr.(Pa) 600 500 400 200 0 500 1000 1500 2000 A 4,0 3,0 2,0 1,0 Caudal/Flow Rate (m3/h) 3500 300 100 2500 3000 Pr.Estática/Static Pr.(Pa) 300 250 200 100 50 0 0 500 1500 1000 2000 3000 A 3,0 1,0 0,0 Caudal/Flow Rate (m3/h) 150 2500 3500 2,0 Pr.Estática/Static Pr.(Pa) 600 500 400 200 0 500 1000 1500 2000 A 4,0 3,0 2,0 Caudal/Flow Rate (m3/h) 300 100 2500 3000 0 5,0 Pr.Estática/Static Pr.(Pa) 600 500 400 200 0 1500 2000 A 4,0 3,0 2,0 Caudal/Flow Rate (m3/h) 300 100 2500 3000 5,0 3500 ErP
BM-D • CBM-D • CBM-D/AL • CBM-D Silent 12/12 M6 3/4 cv 12/12 M6 1 cv 12/12 T6 1,5 cv 15/15 T6 3 cv Luymar se reserva el derecho a modificar los datos sin previo aviso. A Pr.Estática/Static Pr.(Pa) 350 300 250 100 50 0 0 1000 2000 3000 4,0 3,0 2,0 Caudal/Flow Rate (m3/h) 4000 5000 5,0 200 150 Pr.Estática/Static Pr.(Pa) 350 300 250 100 50 0 0 1000 2000 3000 5,0 4,0 3,0 Caudal/Flow Rate (m3/h) 4000 5000 6,0 200 150 7,0 A A Pr.Estática/Static Pr.(Pa) 350 300 250 100 50 0 0 1000 2000 3000 4,0 3,0 2,0 Caudal/Flow Rate (m3/h) 4000 5000 5,0 200 150 6000 7000 6,0 A Pr.Estática/Static Pr.(Pa) 500 300 100 0 0 2000 4000 4,0 3,0 Caudal/Flow Rate (m3/h) 6000 5,0 200 8000 10000 6,0 400 ErP
Rev.01
